Endress+Hauser PMP23-11H3/0 Cerabar Pressure Transmitter

Part number: PMP23-11H3/0. The Cerabar PMP23 is a compact pressure transmitter designed for absolute and gauge pressure measurement in hygienic applications within the food, beverage, and pharmaceutical industries.

Full model name: Endress+Hauser Cerabar PMP23-11H3/0

Application: Ideal for pressure monitoring in hygienic environments, including CIP/SIP cleaning processes, dairy production, and beverage bottling lines.

Technical Specifications:
• Measuring Range: 0 to 10 bar
• Output Signal: 4-20 mA analog
• Power Supply: 10 to 30 V DC
• Accuracy: 0.3% of span
• Material: 316L Stainless Steel housing and diaphragm
• Process Temperature: -10 to +100°C (up to +135°C for 1 hour during SIP)
• Protection Rating: IP65/IP67/IP69 (depending on electrical connection)
• Process Connection: Fully welded hygienic design

Technical Documentation:
Verify Technical Documentation via Google
