Endress+Hauser FTL31-12X0/0 Liquiphant Vibronic Point Level Switch

Part number: FTL31-12X0/0. This vibronic point level switch is designed for liquid detection in tanks, vessels, and pipes, providing overfill prevention and pump dry-run protection.

Full model name: Liquiphant FTL31-12X0/0

Application: Used in industrial machinery, cleaning systems, filter systems, and cooling or lubrication vessels for reliable level monitoring regardless of conductivity or turbulence.

Technical Specifications:
• Supply Voltage: 10-30 V DC
• Output Type: 3-wire DC-PNP
• Measuring Principle: Vibronic (Tuning Fork)
• Material: 316L Stainless Steel housing and sensor
• Process Temperature: Up to 150 C (302 F)
• Process Pressure: -1 to +40 bar (-14.5 to +580 psi)
• Viscosity Range: 1 to 10000 mPa.s
• Medium Density: > 0.7 g/cm3 (standard)
