Endress+Hauser PMP23-18F4/156 Cerabar PMP23 Pressure Transmitter

Part number: PMP23-18F4/156 The Cerabar PMP23 is a compact pressure transmitter designed for absolute and gauge pressure measurement in hygienic applications. It features a fully welded 316L stainless steel construction and a piezo-resistive measuring cell with a flush-mounted diaphragm.

Full model name: Cerabar PMP23-18F4/156

Application: Food and beverage industry, pharmaceutical processes, and hygienic liquid or gas pressure monitoring.

Technical Specifications:
• Measuring Range: 0 to 0.6 bar
• Output Signal: 4-20 mA
• Accuracy: 0.3% of full scale
• Material: 316L Stainless Steel (1.4435)
• Process Temperature: -10 to +100 degrees Celsius (up to 135 degrees for 1 hour)
• Protection Rating: IP67/IP69
• Measuring Principle: Piezo-resistive
