ABB M3AA 160 MLA 2 IMB3/IM1001 IE3 Electric Motor

Part number: M3AA 160 MLA 2 IMB3/IM1001 is a genuine ABB three-phase squirrel cage induction motor. This motor is designed for reliable operation in various industrial applications, offering IE3 Premium Efficiency.

Full model name: ABB M3AA 160MLA 2 IE3 Electric Motor

Application: This ABB M3AA series motor is suitable for general industrial use and standard OEM applications, providing process performance for a wide range of machinery and systems.

Technical Specifications:
• Manufacturer: ABB
• Part Number: M3AA 160 MLA 2
• Product Code: 3GAA161410,ADK,067
• Power: 11 kW
• Number of Poles: 2
• Rated Speed: 2943 r/min (at 50 Hz, 400V)
• Rated Voltage: 400 V Delta (D) / 690 V Star (Y) at 50 Hz
• Frame Size: IEC 160M/L
• Mounting: IMB3/IM1001 (Foot Mounted)
• Efficiency Class: IE3 Premium Efficiency
• Enclosure Protection: IP55
• Frame Material: Aluminum
• Product Net Weight: 91 kg
• Item Weight (as supplied): 106 kg
• Ambient Temperature: 40 °C
• Insulation Class: F / Temperature Class B
• Cooling System: IC411 self-ventilated
• Terminal Box Position: Top
• Terminal Box Entries: 2xM40 + M16
• Year of manufacture: 2024
• Condition: New old inventory, surplus from a cancelled project. Available for immediate delivery at surplus pricing.
