Vega PS63.XXNFDHKMXX Compact Radar Level Sensor

Part number: PS63.XXNFDHKMXX. The VEGAPULS 63 is a radar sensor designed for continuous level measurement of aggressive liquids or applications with stringent hygienic requirements. It features an encapsulated antenna system that protects against contamination and ensures maintenance-free operation in storage tanks and process vessels.

Full model name: VEGAPULS 63 PS63.XXNFDHKMXX

Application: Ideal for chemical processing, food and beverage production, pharmaceutical manufacturing, and water treatment systems involving corrosive media or sanitary environments.

Technical Specifications:
• Measuring Range: Up to 35 m (114.8 ft)
• Measurement Accuracy: ±2 mm
• Process Temperature: -196 to +200 °C
• Process Pressure: -1 to +16 bar (-100 to +1600 kPa)
• Output Signal: 4-20 mA HART
• Housing Material: Plastic, Aluminum, or Stainless Steel options (IP66/IP67)
• Wetted Parts: PTFE, PFA, or PVDF encapsulated antenna
• Beam Angle: 10 degrees (depending on antenna size)

Technical Documentation:
Operating Manual
