Vega 77136 Vegaswing 51 Vibrating Level Switch

Part number: 77136 is a universal vibrating level switch designed for precise liquid detection in industrial vessels and pipelines. This compact sensor utilizes a tuning fork energized at its resonance frequency to detect limit levels with millimeter accuracy, functioning independently of mounting position.

Full model name: VEGASWING 51 Vibrating Level Switch

Application: Overfill protection, dry run protection, pump protection, and limit level detection in liquids such as water, oils, and chemicals.

Technical Specifications:
• Operating Voltage: 20-253 V AC/DC (50/60 Hz)
• Process Pressure: -1 to 64 bar (-100 to 6400 kPa)
• Process Temperature: -40 to +100 °C (Standard)
• Wetted Parts Material: 316L Stainless Steel
• Housing Material: 316L and Plastic PEI
• Protection Rating: IP67
• Switching Delay: 500 ms (on/off)
• Liquid Density: 0.7 to 2.5 g/cm³
• Viscosity: 0.1 to 10000 mPa s

Technical Documentation:
Operating Manual
