Kongsberg RDO-16 Part Number 8100155 Remote Digital Output Module
Technical Specifications
Product Details & Description
Part Number: 8100155
Model: Kongsberg RDO-16 Remote Digital Output Module
New unused Item. In Stock for Immediate Delivery. 14-Day Return & Money-Back Guarantee.
Description
The Kongsberg RDO-16 is a versatile 16-channel digital output module designed to remotely control relays, solenoid valves, and indicator lights in marine and industrial automation settings.
Technical Specifications
Part Number: 8100155
Output Channels: 16 digital output channels with status LEDs (One pole changeover).
Supply Voltage: 18 to 32 VDC.
Output Load Rating: Max 3 Amps at 230 VAC / 32 VDC (Max inductive load Cos(φ)=0.5).
Power Consumption: 4W base consumption (+ 0.5W per active channel).
Communication Interface: 2 CAN ports for redundant host communication.
Operating Temperature: -15 ºC to +70 ºC.
Environmental Compliance: IACS E10, IEC 60945, with vibration resistance up to 4 G.
Ingress Protection (IP): IP20.
Unit Weight: Approximately 1.56 kg to 1.6 kg.
Application
The RDO-16 is widely used in vessel automation for the remote control of machinery such as pumps, valves, and compressors within the K-Chief 600 ecosystem. It allows for precise execution of binary commands from the bridge or engine control room, utilizing isolated relay outputs to ensure system stability and protection against cross-interference.
