End Armaturen BK561006 Wafer Ball Valve DN40 PN16

Part number: BK561006. This wafer-type ball valve is a manual shut-off component designed for industrial piping systems requiring a compact face-to-face dimension. It features a single-piece body construction with a full bore design for optimized flow characteristics.

Full model name: Wafer-ball valve DN40 PN16 GG25/PTFE-NBR

Application: Water supply, plant engineering, and industrial vacuum systems including Evac marine sanitation networks.

Technical Specifications:
• Nominal Diameter: DN40
• Pressure Rating: PN16 (Max 16 bar)
• Body Material: GG-25 Cast Iron (EN-GJL-250)
• Ball Material: Brass, hard chrome plated
• Seal Material: PTFE (Ball) / NBR (Stem)
• Connection Type: Wafer-type flange connection
• Operation: Manual hand lever
• Temperature Range: -10°C to +100°C
• Weight: 5.0 kg
