Eaton E50Sa Heavy-Duty Limit Switch Body

Part number: E50Sa. This component is a heavy-duty plug-in limit switch body designed for industrial automation and sensing applications within the E50 NEMA series.

Full model name: Eaton E50Sa Heavy-Duty Plug-In Limit Switch Body

Application: Used in machine tools, automotive manufacturing, wastewater treatment, and harsh industrial environments requiring chemical resistance to coolants and hydraulic fluids.

Technical Specifications:
• Contact Configuration: 1 NO - 1 NC (Single-pole)
• Contact Rating: 10A at 240Vac / 1A at 250Vdc
• Enclosure Material: Die-cast zinc
• Environmental Rating: NEMA 1, 3, 3S, 4, 4X, 6, 6P, 13; IP67
• Operating Temperature: -40 to 121 C (-40 to 250 F)
• Mechanical Life: 10000000 cycles
• Electrical Life: 1000000 cycles at full load

Technical Documentation:
Verify Technical Documentation via Google
