Danfoss 180Z0166 Pump Connector
Technical Specifications
Manufacturer:Danfoss
Part Number:180Z0166
Condition:
New
Product Details & Description
Part number: 180Z0166. This genuine Danfoss pump connector is designed for high-pressure desalination systems, specifically for connecting APP series pumps to system piping using a Victaulic interface.
Full model name: Danfoss 180Z0166 Pump Connector M42 x 2-inch Victaulic
Application: Seawater reverse osmosis (SWRO), industrial water treatment, and high-pressure desalination systems utilizing Danfoss APP 5.1-10.2 and APP 11-13 axial piston pumps.
Technical Specifications:
• Thread Size: M42 x 1.5
• Victaulic Connection: 2 inch (60.3 mm)
• Maximum Operating Pressure: 83 bar (1200 psig)
• Body Material: Super Duplex Stainless Steel (UNS S32750 / 1.4410)
• Total Length: 103 mm (4.05 in)
• Net Weight: 0.895 kg
Technical Documentation:
Data Sheet
Full model name: Danfoss 180Z0166 Pump Connector M42 x 2-inch Victaulic
Application: Seawater reverse osmosis (SWRO), industrial water treatment, and high-pressure desalination systems utilizing Danfoss APP 5.1-10.2 and APP 11-13 axial piston pumps.
Technical Specifications:
• Thread Size: M42 x 1.5
• Victaulic Connection: 2 inch (60.3 mm)
• Maximum Operating Pressure: 83 bar (1200 psig)
• Body Material: Super Duplex Stainless Steel (UNS S32750 / 1.4410)
• Total Length: 103 mm (4.05 in)
• Net Weight: 0.895 kg
Technical Documentation:
Data Sheet
Shipping & Logistics
Ships From:Germany
Ships To:Worldwide, excluding sanctioned regions.
Availability:
Ready for immediate worldwide delivery.
