SEW-Eurodrive R97 DRN132M4/TF Helical Gearmotor

Part number: R97 DRN132M4/TF is a helical gearmotor designed for industrial drive applications. This assembly combines a 7.5 kW motor with integrated thermal protection and a speed-reducing gear unit.

Full model name: SEW-Eurodrive R97 DRN132M4/TF

Application: Material handling systems, industrial conveyors, agitators, mixers, and mechanical power transmission drives.

Technical Specifications:
• Specification / Serial Number: 25.8478408101.0001.24.15
• Motor Power Output: 7.5 kW
• Output Torque: 2320 Nm
• Speed Rating: 1468 / 31 r/min
• Operating Voltage: 380-400V / 660-690Y V
• Rated Current: 15.50 / 9.00 A
• Frequency: 50 Hz
• Thermal Motor Protection: TF (PTC Thermistor Sensor)
• Insulation Class: 155 (F)
• Protection Rating: IP55
• Operating Duty: S1 continuous duty, Inverter duty VPWM 3 IEC60034

Availability:
• Condition: New
• Unused surplus unit, available for immediate delivery.
• Storage location: Available globally
