Pj Control 2811284 MACX MCR-UI-UI Signal Conditioner

Part number: 2811284 is a genuine Phoenix Contact MACX MCR-UI-UI signal conditioner, supplied by PJ CONTROL OY. This configurable 3-way isolating amplifier is designed for the electrical isolation, filtering, amplification, and conversion of standard analog signals in industrial waste management systems.

Full model name: MACX MCR-UI-UI Signal Conditioner

Application: Used in incinerator components for dry and wet waste processing, industrial automation, and hazardous zone 2 signal isolation.

Technical Specifications:
• Input Signal: Configurable voltage (0 mV to 100 V) and current (0 mA to 100 mA) signals
• Output Signal: Configurable voltage (0 V to 10 V) and current (0 mA to 20 mA) signals
• Power Supply: 24 V DC (19.2 V DC to 30 V DC)
• Isolation: 3-way electrical isolation with 2.5 kV test voltage
• Configuration: Over 1600 signal conversions adjustable via front-facing DIP switches
• Safety Rating: SIL 2 according to EN 61508
• Connection: Screw connection technology
• Mounting: DIN rail mounting (12.5 mm width)
• Operating Temperature: -20 °C to 70 °C

Technical Documentation:
Operating Manual
