Pevasa ECO-PA Polyamide Filter Vessel, Part Number: 21842723-T&B-218-42X72, 90MM
Pevasa ECO-PA Polyamide Filter Vessel, Part Number: 21842723-T&B-218-42X72, 90MM
Supplier Part Number: 21842723-T&B-218-42X72, 90MM
Application Reference Number: 15253
New item: OEM component in perfect condition.
Ships Immediately: In stock, ready for immediate delivery.
Competitive Surplus Price: Limited-time offer while stock lasts.
Fast, Reliable Delivery: Dispatched directly from Germany.
Supplier's Description Match Guarantee: No surprises.
A large-scale filter vessel from the PEVASA ECO-PA series. It is constructed from Polyamide 6, a material that is 100% recyclable, and is designed to be pressure and vacuum resistant with a working pressure of up to 10 bar.
This filter vessel is a core component for industrial filtration systems. Its vacuum resistance allows for use in a broader range of applications than simple pressure vessels, making it suitable for water treatment plants and reverse osmosis systems.
Below is a tech sheet for this product. For more details, see the Pevasa model guideline.
| Parameter | Specification | Source Reference (Guide Page) |
| Product Identifier | ||
| Official Ordering Code | 21842723 | Page 2 |
| Model Information | ||
| Design Code / Model | 218 | Page 10 |
| Product Line | ECO-PA TOP&BOTTOM | Page 10 |
| Configuration | Lateral Inlet/Outlet, Accessories Assembled | Page 10 |
| Physical Dimensions | ||
| Diameter (Nominal) | 42 inches | Page 2 (logic) |
| Height (Nominal) | 72 inches | Page 2 (logic) |
| Connections | ||
| Connection Code | 3 | Page 10 |
| Type | Lateral Glue Connection | Page 10 |
| Size (Nominal) | 3" / D90 / DN75 | Page 10 |
|
Materials & Construction
|
||
| Vessel Material | PA-6 Polyamide | Page 10 |
| Internal Liner | PE (Polyethylene) Liner | Page 10 |
| Flanges | Top & Bottom Blind Flanges | Page 10 |
| Standard Color | RAL 5017 (Blue Pigmented) | Page 10 |
| Operational Limits | ||
| Max. Working Pressure | 10 bar | Page 10 |
| Max. Working Temperature | $75^{\circ}C$ | Page 10 |
| Vacuum Rating | Vacuum Resistant (Aspiration Allowed) | Page 10 |
| Internal System | ||
| Top Distributor | Single Nozzle, R2A | Page 10 |
| Bottom Distributor | Star, 6 or 8 arms | Page 10 |
| Standard Nozzle Slot | 0.2 mm | Page 10 |
| Equipment Manufacturer | Evac |
| Component Manufacturer | Pevasa |
| Condition | New |
| Location | Germany |
