Makron Automation 6EP3334-8SB00-0AY0 Sitop PSU8200 Stabilized Power Supply
Technical Specifications
Manufacturer:Makron Automation
Part Number:6EP3334-8SB00-0AY0
Condition:
New
Product Details & Description
Part number: 6EP3334-8SB00-0AY0. This SITOP PSU8200 is a , regulated technology power supply designed for automated systems and machines. It features a 1-phase wide-range input and provides a stabilized 24 V DC output at 10 A.
Full model name: SITOP PSU8200/1AC/24VDC/10A
Application: Industrial automation, control cabinet power distribution, and instrumentation systems requiring high plant availability and overload protection.
Technical Specifications:
• Input Voltage: 120/230 V AC (85-132 V / 170-264 V range)
• Output Voltage: 24 V DC (Adjustable 24-28.8 V via potentiometer)
• Output Current: 10 A
• Output Power: 240 W
• Efficiency: 94%
• Protection Class: IP20
• Mounting: 35 mm DIN Rail (35x7.5/15)
• Operating Temperature: -25 to 70 Deg C
• Dimensions: 55 mm W x 125 mm D x 125 mm H
• Weight: 1.0 kg
Technical Documentation:
Operating Manual
Full model name: SITOP PSU8200/1AC/24VDC/10A
Application: Industrial automation, control cabinet power distribution, and instrumentation systems requiring high plant availability and overload protection.
Technical Specifications:
• Input Voltage: 120/230 V AC (85-132 V / 170-264 V range)
• Output Voltage: 24 V DC (Adjustable 24-28.8 V via potentiometer)
• Output Current: 10 A
• Output Power: 240 W
• Efficiency: 94%
• Protection Class: IP20
• Mounting: 35 mm DIN Rail (35x7.5/15)
• Operating Temperature: -25 to 70 Deg C
• Dimensions: 55 mm W x 125 mm D x 125 mm H
• Weight: 1.0 kg
Technical Documentation:
Operating Manual
