Kongsberg RDI-32 Part Number 8100154 Remote Digital Input Module

Part Number: 8100154

Model: Kongsberg RDI-32 Remote Digital Input Module

New unused Item. In Stock for Immediate Delivery. 14-Day Return & Money-Back Guarantee.

Description

Part number 8100154, the Kongsberg RDI-32, a high-density remote digital input module engineered for acquiring ON/OFF signals from field devices within high-reliability maritime automation networks.

Technical Specifications

Input Channels: 32 digital channels with independent LED status indicators.

Supply Voltage: 18 to 32 VDC.Power Consumption: 16W maximum for RDi-32xe (all inputs active).

Communication Interface: 2 CAN ports for redundant CANopen 4.0 high-speed field bus communication.

Signal Type: Dry contacts (switching level approx. 1.5 mA).

Operating Temperature: -15 ºC to +70 ºC.

Environmental Compliance: IACS E10, IEC 60945, and Type Approved by DNV, LRS, BV, and ABS.

Ingress Protection (IP): IP20.

Unit Weight: Approximately 1.8 kg to 1.92 kg.

Application

This module is typically integrated within the Kongsberg K-Chief 600 and AutoChief 600 systems to monitor alarm statuses and equipment conditions in harsh environments like engine rooms. It serves as a crucial interface for processing signals from switches, level sensors, and other binary field devices, ensuring that real-time status data is transmitted over redundant CANbus lines to the central operator station.
