Ifm Electronic PA3029 Pressure Transmitter

Part number: PA3029. This pressure transmitter features a ceramic measuring cell designed for precise vacuum and relative pressure monitoring in industrial and railway applications.

Full model name: PA-0-1-RBR14-A-ZVG/US/ /V

Application: Used for monitoring liquids and gases in vacuum generation, pneumatic systems, and harsh industrial environments requiring high overload protection.

Technical Specifications:
• Measuring range: -1 to 0 bar (-1000 to 0 mbar)
• Output signal: 4-20 mA analogue current
• Operating voltage: 9.6 to 32 V DC
• Process connection: G 1/4 internal thread
• Electrical connection: M12 connector with gold-plated contacts
• Housing material: Stainless steel 316L (1.4404)
• Wetted parts: Ceramics, FPM (Viton), and stainless steel
• Pressure rating: 10 bar (145 psi)
• Burst pressure: 30 bar (435 psi)
• Protection class: IP 65 / III
