Georg Fischer 161017113 PVC-U Pipe d90 PN16

Part number: 161017113. This metric PVC-U pressure pipe is designed for industrial fluid transport, featuring a 90mm outer diameter and a PN16 pressure rating.

Full model name: Georg Fischer PVC-U Pipe Grey SDR13.6 PN16 metric d90

Application: Water treatment, chemical process industry, marine engineering, and vacuum lines.

Technical Specifications:
• Material: PVC-U (Polyvinylchloride unplasticised)
• Outer Diameter (d): 90 mm
• Wall Thickness (e): 6.7 mm
• Nominal Pressure: PN16 (16 bar at 20°C)
• Standard Dimension Ratio: SDR 13.6
• Color: Dark Grey (RAL 7011)
• Temperature Range: 0°C to +60°C
• Standards: DIN 8061/62, DIN EN ISO 15493
