Festo 3568055 SRBG-C1-N-1-P-M12 Sensor Box

Part number: 3568055. This inductive dual sensor box is designed for electrical feedback and position monitoring of process valves actuated by pneumatic quarter-turn actuators.

Full model name: SRBG-C1-N-1-P-M12

Application: Used in process automation for monitoring valve positions on actuators with VDI/VDE 3845 connection patterns.

Technical Specifications:
• Measuring Principle: Inductive
• Switching Output: PNP
• Switching Element Function: N/O contact
• Operating Voltage Range: 10V - 30V DC
• Electrical Connection: M12x1 plug, 4-pin, A-coded
• Degree of Protection: IP67
• Housing Material: PBT (Polybutylene Terephthalate)
• Ambient Temperature: -25 to 70°C
• Mounting Type: Threaded, direct mounting to VDI/VDE 3845
