Evac 6542546 Evacinshine Toilet Complete

Part number: 6542546 The EvacInshine is a complete vacuum toilet assembly designed to replace existing Ifö wall-mounted models in marine and industrial vacuum systems. This unit integrates an Evac 910 wall model USPH with a Prestige seat, specifically engineered for silent operation and compliance with USPH (United States Public Health) standards.

Full model name: EvacInshine Toilet Complete with Evac 910 Wall Model USPH Prestige

Application: Marine sanitation systems, cruise ship retrofits, and commercial vacuum sewage systems requiring gravity-to-vacuum conversion for Ifö wall-mounted fixtures.

Technical Specifications:
• Base Component: Evac 910 Wall Model USPH
• Seat Type: Prestige
• Compatibility: Direct replacement for Ifö wall model toilets
• Material (Adapter Frame): Aluminum (DIN1028)
• Material (Cover/Pipe): PVC
• Net Weight: 24.2 kg
• Shipping Weight: 27.5 kg
• Shipping Volume: 0.168 m³
• Flush Control: Pneumatic push button
• Compliance: USPH (United States Public Health) compliant
