Evac 5451460 Centrifugal Pump Se 044A

Part number: 5451460 is a centrifugal maceration pump designed for marine vacuum sewage systems. It is specifically engineered for continuous high-load sewage collection and vacuum generation in unstable marine networks.

Full model name: Centrifugal Pump Evac SE 044A 60Hz

Application: Sewage transport and maceration in marine vacuum toilet collection units and sewage treatment plants.

Technical Specifications:
• Model: SE 044A
• Motor Power: 4.6 kW
• Electrical Supply: 3x440V, 60Hz
• Impeller Diameter: 210 mm
• Rotation Speed: 1730 RPM
• Protection Class: IP55
• Insulation Class: F
• Connection Size: DN100
• Pump Casing Material: Cast iron EN-GJL-200
• Impeller Material: Ductile iron EN-GJS-500
• Shaft Material: Stainless steel SIS 2324
• Mechanical Seals: Fluoric rubber (Viton) and Silicon carbide coated carbon
