Evac 5437598 Pressure Switch Rt121

Part number: 5437598 is a pressure switch designed for vacuum and low-pressure monitoring in marine and industrial systems. This component is a specialized Danfoss RT series switch integrated into Evac vacuum collection systems to regulate start/stop cycles and alarm thresholds.

Full model name: Evac 5437598 Pressure Switch BPS 3/8 RT121

Application: Vacuumarator systems, marine sewage collection, industrial vacuum monitoring, and low-pressure air or oil systems.

Technical Specifications:
• Regulation Range: -1 to 0 bar
• Differential Range: 0.09 to 0.4 bar
• Pressure Connection: G 3/8 Male
• Contact Function: SPDT (Single Pole Double Throw)
• Reset Function: Automatic
• Enclosure Rating: IP66
• Maximum Working Pressure: 7 bar
• Ambient Temperature Range: -50 to 70 C
• Electrical Connection: 2xPg 13.5 screwed cable entry
