Evac 5433572 Straight Connection Sleeve

Part number: 5433572 is a genuine EPDM straight connection sleeve designed for vacuum toilet discharge systems. It provides a secure, airtight interface between the toilet bowl outlet and the vacuum piping network.

Full model name: Evac 5433572 Connection Sleeve 50/50 Straight

Application: Used in marine and land-based vacuum sanitation systems, specifically compatible with Evac 90, 900, 910, and Optima series vacuum toilets.

Technical Specifications:
• Material: EPDM Rubber
• Configuration: Straight 50/50 connection
• Pipe Compatibility: Fits O.D. 48-52 mm pipes
• Nominal Diameter: 50 mm
• Net Weight: 0.2 kg
• Chemical Resistance: Resistant to standard sanitation cleaning agents and waste effluent
