Elro Peristaltic Pump XP800
Technical Specifications
Product Details & Description
Tetromi supplies the high-capacity ELRO XP series, characterized by maximum discharge volumes at low rotary speeds to optimize hose service life. These units are equipped with a newly developed vacuum system integrated directly into the torsion-resistant pump housing.
Part number: XP800. The ELRO XP series flagship model provides maximum pumping capacity at low rotary speeds. The large cross-section hose handles the highest wetted-solids content in the range while maintaining constant flow rates under absolute vacuum. Engineered for the most demanding large-scale industrial and environmental interventions.
Full model name: ELRO Peristaltic Pump XP800.
Application: Large-scale environmental technology, wastewater processing, and heavy industrial wetted-media transfer.
Technical Specifications:
• Max. flow rate: 46.0 m3/h
• Max. system pressure: 10 bar (145 psi)
• Max. dry suction lift: 9.5 mWs
• Internal hose diameter: 91 mm
• Weight without drive: 693 kg
• Lubricant capacity: 10 Liters.
Technical Documentation:
Operating Manual and Installation Instructions
Technical Datasheet for ELRO Series IP and XP Peristaltic Pumps
