Elro Peristaltic Pump IP800

ELRO IP Series peristaltic pumps are a robust stationary solution for the gentle transport of liquid or highly viscous media. Tetromi supplies complete units or customized configurations of the solitary wetted wear part (the hose) to ensure absolute chemical compatibility with your shear-sensitive products.  The IP series features a patented vacuum system that creates a permanent vacuum inside the housing, ensuring constant flow rates and maximum suction lift of 9.5 mWs across the service life of the hose.

Model: ELRO Peristaltic Pump IP800.

Application: Primary industrial pumping for ceramic and porcelain production, heavy chemical industries, and large-scale waste disposal.

Technical Specifications:
• Max. flow rate: 28.0 m3/h
• Max. pump pressure: 13 bar (188 psi)
• Max. dry suction lift: 9.5 mWs
• Internal hose diameter: 70 mm
• Weight without drive: 620 kg
• Lubricant capacity: 10 Liters.

Technical Documentation:
Operating Manual and Installation Instructions
Technical Datasheet for ELRO Series IP and XP Peristaltic Pumps
IP800 Datasheet
