Elfa Distrelec X004356 Power Supply Pvse400/24-40

Part number: X004356 is a three-phase primary switched mode power supply designed for industrial automation and waste management systems. This unit provides a stabilized 24 Vdc output with a robust 40 A current rating, optimized for voltage delivery.

Full model name: BLOCK PVSE 400/24-40 Power Vision Economy

Application: Industrial automation, control cabinet construction, mechanical system engineering, and Evac dry/wet waste equipment systems.

Technical Specifications:
• Input Voltage: 3 x 400 - 500 Vac (Range: 340 - 550 Vac / 480 - 780 Vdc)
• Output Voltage: 24 Vdc (Adjustable 22.8 - 28.8 Vdc)
• Output Current: 40 A
• Power Rating: 960 W (Max 1.152 kW)
• Power Boost: 60 A for 4 seconds / 50 A for 8 seconds
• Top Boost: 100 A for 50 ms to trip circuit breakers
• Efficiency: 92% typical
• Mounting Type: DIN Rail Mount (Panel installation)
• Signaling: DC OK relay contact and LED status display (Green/Red)
• Connection: Service-friendly spring-loaded connector system
• Operating Temperature: -25 °C to 70 °C
