Clorius Controls 2210428 M1F 15/9 PN16 Cast Iron 2-Way Control Valve

Part number: 2210428 is a 2-way control valve designed for fluid regulation in industrial steam systems and fluid control installations. It features a single-seated design intended for temperature adjustment and process fluid control.

Full model name: Clorius Controls TYPE M1F (M1F-15/9 / M1F2210426)

Application: Industrial steam systems, fluid control installations, central heating plants, cooling circuits, and process media control.

Technical Specifications:
• Nominal Diameter: DN 15/9
• Pressure Rating: PN 16
• Valve Type: 2-Way Single-Seated Control Valve
• Body Material: Cast Iron (EN-GJS-400-15)
• Internal Components: Stainless Steel (spindle, seat, and cone)
• Connection Type: Flanged ends drilled according to EN 1092-2 PN 16
• Actuator Connection Thread: G1B ISO 228
• Valve Characteristic: Quadratic
• Seat Leakage: Less than 0.05% of full flow (VDI/VDE 2174)

Availability:
• Condition: New
• Standard availability lead time is 14 days.
• Storage location: Germany & Netherlands

Technical Documentation:
Technical Documentation via Google
